CASE REPORT

Pancreatic Mucinous Cystic Neoplasm in a Male Patient

Riccardo Casadei¹, Raffaele Pezzilli², Lucia Calculli³, Donatella Santini⁴, Giovanni Taffurelli¹, Claudio Ricci¹, Marielda D’Ambra¹, Francesco Minni¹

Departments of ¹Surgery, ²Internal Medicine, ³Radiology, and ⁴Pathology, “S.Orsola-Malpighi” Hospital, Alma Mater Studiorum, University of Bologna. Bologna, Italy

ABSTRACT

Context Mucinous cystic neoplasm (MCN) of the pancreas usually affects female patients and is characterized by an ovarian-type stroma. From literature review, only 9 cases of MCNs have been reported in male patients. Case report We describe the 10^th case of a MCN in a 65-year-old male patient who underwent a distal pancreatectomy with spleen resection and standard lymphadenectomy. Conclusions MCN may rarely regard male patients, probably for embryological abnormalities.

INTRODUCTION

Pancreatic cystic neoplasms represent about the 1% of all pancreatic tumors [1]. Among pancreatic cystic tumors, the WHO classification [2] recognized mucinous cystic neoplasm (MCN) as a tumor of the premenopausal female patients, characterized by the presence of an ovarian-type stroma in the pathological examination of the specimen. Herein, we describe a very rare case of a MCN in a male patient with the aim to understand how is possible the presence of this tumor in a male patient.

CASE REPORT

A 65-year-old man was seen as outpatient at our Pancreas Unit in March 2012. He was a drinker of 50 grams of pure alcohol per day from 25 to 65 years of age and heavy smoker (40 cigarettes per day from the 18^th to 50^th years of age. At the age of 50 years a diagnosis of diabetes mellitus type 2 was made and the patient assumed metformin at a dosage of 2,000 mg per day and glicazide at the dosage of 60 mg per day. He never experienced abdominal pain and the reason why he was admitted to our unit was the ultrasonographic detection of a cyst located in the body-tail of the pancreas of 3.8 cm of diameter one year before. On admission, clinical examination revealed no major abnormalities and his body mass index was 30 kg/m². Laboratory investigations were unremarkable, a part the finding of a poor glycemic control (glucose 189 g/dL, reference range: 70-110 g/dL; concentrations of hemoglobin A_1c (HbA_1c) of 75 mmol/mol, reference range: 20-42 mmol/mol). The tumor markers (CEA, CA 19-9) were normal. Abdominal contrast-enhanced computed tomography was carried out and showed an increase of the unilocular pancreatic cyst from 38 mm, seen one year before at US, to 49 mm in diameter. To better evaluate the presence of a link between the cyst and the pancreatic tree, a magnetic resonance cholangiopancreatography (MRCP) was carried-out. This examination showed a well-shaped pancreatic gland with a 49 mm diameter fluid mass localized in the body, without septa or endoluminal solid components, without a clear communication with the main pancreatic duct (Figure 1). The lesion did not seem to infiltrate the peripancreatic vessels, but, for its size, it seemed to slightly constrict the splenic artery and vein. Finally, contrast enhanced ultrasonography confirmed the strict connection with the splenic vessels, without their infiltration, and revealed the absence of contrast-enhancement in the cyst’s content and wall, as well as the presence of communication with the main pancreatic duct. Because the increase of the cyst, the patient underwent a distal pancreatectomy with spleen resection and standard lymphadenectomy.

Figure 1. Magnetic resonance cholangiopancreatography (MRCP) showed a 49 mm fluid mass in the body-tail of the pancreas without septa or mural nodules and without communication with the Wirsung duct.

Macroscopically, the examination of the specimen showed a cystic lesion measuring 40 mm of maximum diameter. The cut surface demonstrated a unilocular cystic pattern with smooth and white inner walls, containing viscous whitish mucin. The cyst showed a peripheral pattern of growth, without communication with the pancreatic ductal system. The remaining parenchyma was normal and the transection margin was 20 mm far from the mass. Microscopically, the cystic lesion showed two distinct components: a mucinous epithelial layer showing low-grade dysplasia and an ovarian-type stroma (according to WHO 2010 [3]). Immunohistochemically, the stromal layer was positive for estrogen, progesterone and calretinin receptors (Figure 2). According to these findings, the cystic lesion was diagnosed as a MCN having ovarian stroma of the pancreas; lymph nodes (n=6) were negative.

Figure 2. a. Microscopically (hematoxilin-eosin x100), an ovarian type stroma layer, that appears as a band of densely packed spindle cells, is covered by a mucinous epithelial low grade dysplasia layer. b. Immunohistochemical analysis (x100) of the ovarian type stroma, showed expression of receptors for estrogen.

The postoperative course was complicated by a pancreatic fistula, grade B, treated with a CT-guided abdominal drainage in post-operative day 7. A contrast enhanced CT scan, performed in postoperative day 12, showed a reduction of the abdominal collection and the patient was discharged in postoperative day 14 with a minimal residual drainage output.

DISCUSSION

In 1996 the WHO classification defined mucinous cystic neoplasms as cystic epithelial neoplasms composed of columnar, mucin-producing epithelium, supported by ovarian-type stroma, usually in premenopausal female patients. The ovarian-type stroma appears as a band of densely packed spindle cells beneath the epithelium; its presence has become a critical requirement to make diagnosis of MCNs [2].

The distinctive aspect of our case was that the ovarian-type stroma was found in a male patient. Nine cases only regarding male patients with WHO criteria for diagnosis of MCN have been reported in literature and our case represents the 10^th. Among the 9 cases described in literature, 3 cases were demonstrated in a recent multi-institutional study for MCNs with ovarian-type stroma by the Japan Pancreas Society, collecting a total of 156 cases of MCNs [4]; one case was described in a Japanese male in 2005 [5]; another case was counted by Reddy et al. [6] in a 56 cases record of MCN in 2004. Only 4 cases were fully described: a 39-year-old man in 2011 [7], a 25-year-old man and a 28-year-old man in 2005 [8, 9], and a 43-year-old man in 1998 [10] (Table 1). Unlike female cases, in which the tumor develops in pre-menopausal age, in male patients the age of diagnosis is highly variable ranging from 25 to 72 years of age (mean age 41.7 years). The majority of patients was symptomatic (4/5; 80%); the tumor was usually benign, located in the tail and with a mean diameter of 42 mm, as in our case. In all cases, the preoperative diagnosis was different from MCN and all patients were treated surgically.

Table 1. Epidemiological and pathological characteristics of the MCNs in male patients (n=10) described in literature.
Study	Number of male patients	Age (years)	Site	Size	Symptoms	Preoperative Diagnosis	Surgical Approach	Histology
Wouters et al., 1998 [10]	1/1	43	Tail	25 mm	Abdominal pain	Pseudocyst	Spleen-preserving DP	Adenoma
Reddy et al., 2004 [6]	1/56	NA	NA	NA	NA	NA	NA	Adenoma
Hifumi et al., 2005 [5]	1/1	NA	NA	NA	NA	NA	NA	Adenoma
Suzuki et al., 2005 [8]	1/1	25	Tail	50 mm	Abdominal pain	BD-IPMN	DP	Adenoma
Goh et al., 2005 [9]	1/1	28	Tail	30 mm	Abdominal pain, weight loss	Carcinoma with cystic degeneration	Spleen-preserving DP	Adenoma
Tokuyama et al., 2011 [7]	1/1	39	Body-tail	65 mm	Back pain	Cystic neoplasia	DP	Adenoma
Yamao et al., 2011 [4]	3/156	26 36 72	Body-tail	NA	NA	NA	DP DP DP	MI carcinoma Adenoma Adenoma
Present case, 2012	1/1	65	Body-tail	40 mm	No	BD-IPMN	DP	Adenoma
BD IPMN: branch duct intraductal papillary mucinous neoplasm; DP: distal pancreatectomy; MI carcinoma: minimally invasive carcinoma; NA: not available

The question why a MCN with ovarian-type stroma affects a male patient is not clear. Currently, there are two hypothesis concerning the origin of ovarian-type stroma in MCNs in male: 1) ovarian stroma arises from rests of embryologic ovarian tissue deposited in the pancreas and this hypothesis is supported by the close proximity of the left ovarian primordium to the body-tail of the dorsal pancreas in fetal life; 2) ovarian stroma represents a recapitulation of periductal fetal mesenchymal connective tissue, the primitive mesenchymal tissue seen around the pancreatic and hepatic ducts in the developing fetus [1, 11]. Furthermore, regardless of its origin, it is also clear that this stroma is hormone sensitive: in fact, it is often admixed with luteal-type cells and it regularly expresses estrogen and progesterone receptors [1, 11]. This finding, together with the first pathogenetic hypothesis, could explain the higher incidence of MCN in peri-menopausal female patients, which are stimulated by progesterone and estrogen during their life.

On the contrary, the second hypothesis seems to be the only one that could explain a MCN’s onset in male patients. According to this, the pathogenesis would start with a process of hormonal reactivation of cells from the periductal fetal mesenchyme, that leads to the proliferation of an ovarian-type stroma and a secondary activation of the ductal epithelium. However, in our opinion, this hypothesis is not able to explain the coexistence of luteal-type cells, typically alpha-inhibin and calretinin immunohistochemically positive, and described resembling luiteinized stroma of the ovary. Nevertheless, these luteinized cells are very similar, morphologically and immunohistochemically, to Leydig cells. Thus, also in a man this tumor may arise from a residual embryonic undifferentiated sexual cord ridge.

In conclusion, the MCN may rarely regard male patients, probably for embryological abnormalities.

Received July 30^th, 2012 – Accepted September 24^th 2012

Key words Cystadenoma, Mucinous; Male; Neoplasms; Pancreas; Pancreatectomy

Conflicts of interests The authors have no potential conflict of interest

Correspondence
Riccardo Casadei
Department of Surgery
S.Orsola-Malpighi Hospital
Alma Mater Studiorum - University of Bologna
Via Massarenti n. 9
40138 Bologna
Italy
Phone: +39-051.341.541
Fax: +39-051.341.483
E-mail: riccardo.casadei@aosp.bo.it

References

1. Adsay VN. Cystic lesions of the pancreas. Mod Pathol 2007; 20:S71-93.

2. Bosman, FT, Carneiro F, Hruban RH, Theise ND. In: WHO Classification of Tumours. IARC WHO Classification of Tumours, No 3, 2010.

3. Tanaka M, Chari S, Adsay V, Fernandez-del Castillo C, Falconi M, Shimizu M, et al. International consensus guidelines for management of intraductal papillary mucinous neoplasm and mucinous cystic neoplasms of the pancreas. Pancreatology 2006; 6:17-32.

4. Yamao K, Yanagisawa A, Takahashi K, Kimura W, Doi R, Fukushima N, et al. Clinicopathological features and prognosis of mucinous cystic neoplasm with ovarian-type stroma. A multi-institutional study of the Japan pancreas society. Pancreas 2011; 40:67-71.

5. Hifumi M, Fukuda S, Yamane T, Yokomizo H, Kitada H, Kawaguchi T, et al. A case of the pancreatic mucinous cystadenoma in a man with ovarian-type stroma, expressing estrogen and progesteron receptors. Nihon Shokakibyo Gakkai Zasshi 2005; 102:1188-93.

6. Reddy RP, Smyrk TC, Zapiach M, Levy MJ, Pearson RK, Clain JE, et al. Pancreatic mucinous cystic neoplasm defined by ovarian stroma: demographics, clinical features, and prevalence of cancer. Clin Gastroenterol Hepatol 2004; 2:1026-31.

7. Tokuyama Y, Osada S, Sanada Y, Takahashi T, Yamaguchi K, Yoshida K. Mucinous cystic neoplasm of the pancreas in a male patient. Rare Tumors 2011; 3:e14.

8. Suzuki M, Fujita N, Onodera H, Kayaba Y, Suzuki S, Kagaya H, et al. Mucinous cystic neoplasm in a young male patient. J Gastroenterol 2005; 40:1070-4.

9. Goh BK, Tan YM, Kumarasinghe MP, Ooi LL. Mucinous cystic tumor of the pancreas with ovarian-like stroma in a male patient. Dig Dis Sci 2005; 50:2170-7.

10. Wouters K, Ectors N, Van Steenbergen W, Aerts R, Driessen A, Van Hoe L, Geboes K. A pancreatic mucinous cystadenoma in a man with mesenchymal stroma, expressing oestrogen and progesterone receptors. Virchows Arch 1998; 432:187-9.

11. Basturk O, Coban I, Adsay NV. Pancreatic cysts: pathologic classification, differential diagnosis and clinical implications. Arch Pathol Lab Med 2009; 133:423-38.
