CASE REPORT

Poorly-Differentiated Signet-Ring Cell Carcinoma of the Ampulla of Vater: Report of a Rare Malignancy

Metesh Nalin Acharya¹, Nikolaos Panagiotopoulos¹, Patrizia Cohen², Raida Ahmad², Long R Jiao¹

Departments of ¹Surgery and Cancer and ²Histopathology, Hammersmith Hospital. London, United Kingdom

ABSTRACT

Context Signet-ring cell carcinoma (SRCC) of the ampulla of Vater is a very rare clinical entity, which is infrequently reported in medical literature. Case report A 78-year-old woman was admitted with jaundice, pruritus and postprandial vomiting. Abdominal ultrasound and computed tomography scanning demonstrated gross dilatation of the common bile and pancreatic ducts with gallbladder calculi. Endoscopic retrograde cholangiopancreatography suggested a duodenal tumour at the ampulla. The patient underwent Whipple’s procedure with cholecystectomy. Immunohistopathological examination confirmed poorly-differentiated SRCC of the ampulla of Vater. The tumour had infiltrated the duodenal muscularis propria and pancreatic parenchyma, but local lymph nodes were clear (T3N0M0). The patient was disease-free at 6-month follow-up. Conclusions We here report a case of poorly-differentiated SRCC of the Ampulla of Vater. The majority of patients with such tumours undergo pancreaticoduodenectomy, which affords good outcomes in early disease. However, owing to the rarity of cases, the exact prognosis of ampullary SRCC remains as yet undetermined.

INTRODUCTION

Most tumours of the ampulla of Vater are well-differentiated adenocarcinomas. Signet-ring cell carcinoma (SRCC) is a very rare histological variant found at this site, being more common in the stomach than elsewhere in the digestive system [1]. Including the original report by Sekoguchi et al. in 1979 [2], 31 previous cases of ampullary SRCC have been mentioned in medical literature. We here present an elderly patient who underwent Whipple’s procedure, in whom poorly-differentiated ampullary SRCC without nodal metastasis was confirmed on histological examination of the resected specimen.

CASE REPORT

A 78-year-old woman presented to our institution with a three-week history of tiredness, postprandial vomiting, jaundice and pruritus. She additionally reported oily stools. Her past medical history included hypothyroidism, chronic cystitis and a left knee replacement. She was visibly icteric, but physical examination was otherwise unremarkable, without any abdominal tenderness or palpable breast masses. Routine laboratory investigations revealed elevated alanine transaminase 106 IU/L (reference range: 0-40 IU/L), alkaline phosphatase 730 IU/L (reference range: 30-130 IU/L), and bilirubin 182 µmol/L (reference range: 0-17 µmol/L), with normal inflammatory markers.

Abdominal ultrasound demonstrated gross dilatation of the common bile and pancreatic ducts, and gallbladder, the latter containing several small calculi. A 2 cm soft tissue mass was suggested at the level of the ampulla of Vater. Subsequent staging CT scan confirmed the marked common bile and pancreatic duct dilatation. However, no definite ampullary mass lesion was identified; a bulky pancreatic head was noted, with a homogenous texture similar to the rest of the pancreas. There was no ultrasound or CT evidence of local spread, vascular encasement or distant metastatic disease. Endoscopic retrograde cholangiopancreatography (ERCP) suggested a duodenal tumour at the ampulla, but a stent could not be placed across the stricture and biopsy was not taken.

The patient underwent Whipple’s resection and cholecystectomy. At operation, a large mass was found at the head of the pancreas, involving the first and second parts of the duodenum, and invading into the hepatic aspect of the transverse colonic mesentery. Following an uncomplicated post-operative course, the patient was discharged home. She did not receive adjuvant chemoradiotherapy, and had no evidence of recurrence at six-month follow-up.

On histological analysis, an ill-defined lesion measuring 12 mm in maximum dimension was noted near the ampulla, extending to its anterior margin (Figure 1). The tumour measured 30 mm in maximum dimension within the duodenal submucosa, from where it ulcerated into the duodenal mucosa, surrounding blood vessels, the ampullary duct and the common bile duct (Figure 2). It infiltrated the duodenal muscularis propria and extended into the pancreatic parenchyma, reaching 16 mm from the superior mesenteric vein. Although there was extensive perineural invasion with infiltration of the duodenal mucosal and submucosal lymphatics, the pancreatic resection margin was not involved, and 0/13 peripancreatic and 0/10 greater curve lymph nodes were all free of tumour (T3N0M0). Microscopic appearances showed a poorly-differentiated signet-ring cell carcinoma, composed entirely of round cells containing intra-cytoplasmic mucin (Figure 3). Immunohistochemical staining was strongly positive for cytokeratin (CK) 7, CK20, CK8/18, CK19, CEA mono, CA 19-9, CA 125, MUC1 and MUC5AC. Tumour cells showed no expression for MUC2, MUC6, SMAD4, CDX2, ER and PgR. This immunohistochemical staining pattern is highly suggestive of signet-ring cell carcinoma of pancreatobiliary origin [3].

Figure 1. Axial slice of the head of the pancreas demonstrating marked narrowing of the duodenum by peri-ampullary polypoid tumour nodules (arrow). A scale with 1 cm intervals is shown.

Figure 2. Histological section (H&E, x20) showing a diffuse tumour (arrow) located mainly within the duodenal mucosa, encircling the ampullary duct and extending into the pancreatic parenchyma.

Figure 3. Higher magnification (DPAS, x200) reveals poorly-differentiated signet-ring cell carcinoma composed of single, non-cohesive, round and vacuolated cells containing intra-cytoplasmic mucin.

DISCUSSION

Adenocarcinoma of the ampulla of Vater is a rare clinical entity, occurring in less than six cases per million people annually [4]. It accounts for 0.2% of all gastrointestinal and 6% of periampullary malignancies [4, 5]. SRCC represents a variant of adenocarcinoma, characterised by the presence of greater than 50% signet-ring cells with intra-cytoplasmic mucin, and typically eccentrically-located crescent-shaped nuclei [4]. It may arise in any organ, especially in the stomach where it comprises 15-30% of all gastric cancers [5].

We here present the 32^nd report of SRCC of the ampulla of Vater in medical literature (Table 1). From available demographic information, the 30 preceding cases included 16 males and 9 females aged between 32 and 83 years of age. One patient presented with T4 disease, ten patients with T3 disease and eight with T2 disease. Diagnostic imaging detected metastatic lung, liver and bone disease in one patient [6], and multiple pulmonary metastatic deposits in another [7]. Disseminated carcinomatosis was noted on presentation in a Japanese patient [8], whilst leptomeningeal metastases were detected in another patient following adjuvant chemotherapy for ampullary SRCC [9].

Table 1. Published cases of signet-ring cell carcinoma of the ampulla of Vater.

Author	Year	Age (years)	Sex	Tumour size (cm)	TNM	Treatment	Follow-up (months)	Outcome
Sekoguchi [2]	1979	47	Male	2.0x0.8	T3N0M0	Unknown	Unknown	Unknown
Gardner [23]	1990	69	Female	2.0x1.5	T3N0M0	PD	Unknown	Unknown
Arnal-Monreal [24]	1994	71	Male	2.5	T2N0M0	PD	24	Alive
Casella [25]	1994	70	Male	Unknown	TxNxM0	Ampullectomy	12	Alive
Hara [13]	2002	68	Male	1.5x0.8	T2N0M0	PD	10	Alive
Tseng [26]	2002	47	Male	2.0	T3N0M0	PD	6	Alive
Nabeshima [8]	2003	49	Male	0.8	T3NxM1	Chemotherapy	12	Died
Eriguchi [12]	2003	83	Male	1.5x1.2	T3N0M0	PD	18	Alive
Li [4]	2004	56	Female	1.5x1.0	T2N1M0	PD	12	Alive
Ramia [11]	2004	67	Female	1.8	T2N0M0	PD	12	Alive
Fang [27]	2004	53	Male	Unknown	T2N0M0	PD	25	Alive
Zhou [28]	2004	Four cases reported but no further clinicopathological information available
Purohit [6]	2005	32	Female	Unknown	TxNxM1	Declined	Unknown	Unknown
Valeri [14]	2005	66	Male	Unknown	Unknown	PPPD	Unknown	Unknown
Bloomston [29]	2005	58	Female	1.0x0.8	T2N0M0	PD	134	Alive
Akatsu [5]	2007	43	Female	2.0x1.8	T2N0M0	PD	90	Alive
Gao [1]	2009	38	Female	2.0x2.0	T3N0M0	PD	6	Alive
Ishibashi [10]	2009	59	Male	3.0x2.0	T3N0M0	PD	18	Died
Kim [20]	2010	47	Male	3.0x2.0	TxN1Mx	Chemotherapy	12	Died
Gheza [3]	2011	66	Male	Unknown	Unknown	PD	8	Alive
Taş [7]	2011	40	Male	Unknown	TxN1M1	Unknown	Unknown	Unknown
Paplomata [9]	2011	45	Female	3.0	pT4pN1pMX	PD, chemo-radiotherapy	12	Died
García [30]	2011	73	Male	2.1x1.5	T2N1M0	PD	14	Alive
García [30]	2011	74	Male	Unknown	T3N0Mx	Total pancreatectomy	3	Alive
Maekawa [31]	2011	75	Male	2.0x1.5	T3N0M0	PD	6	Died
Terada [17]	2012	74	Female	Unknown	TxNxM0	Stent insertion, chemotherapy	14	Died
Lesquereux-Martínez [21]	2012	78	Female	1.1	TxN1M0	PD, chemotherapy	14	Alive
Daoudi [22]	2012	55	Male	Unknown	pT3N0M0	PD, chemotherapy	8	Alive
Present case	2012	78	Female	3.0	T3N0M0	PD	6	Alive

PD: pancreaticoduodenectomy; PPPD: pylorus-preserving pancreaticoduodenectomy

The rarity of ampullary SRCC is compounded by its unclear histological genesis. Since SRCC is more frequently encountered within gastric epithelium, it has been suggested that this tumour may arise from ectopic gastric mucosa situated at the ampulla [10, 11]. Another theory proposes that SRCC originates from gastric-type metaplasia occurring as a protective response to increased acidity, a recognised phenomenon in peptic ulcer disease [10, 11]. Although peri-tumoural ectopic gastric mucosa was found in two previous patients with SRCC, none was found in our patient, who also did not suffer peptic ulcer disease.

Immunohistochemical staining patterns allowing further classification of ampullary SRCC to a pancreatobiliary- or intestinal-type have been described [3]. Expression of CK7, along with negativity for CK20, CDX-2 and MUC2 signifies pancreatobiliary-type SRCC, and vice-versa. Based on these staining patterns, tumour cells in the present case were suggestive of a pancreatobiliary-type origin, which is associated with a less favourable outcome [3, 12].

It is known that SRCC elsewhere in the gastrointestinal tract has a poor prognosis [1, 3, 5]. Similarly, poorly-differentiated ampullary adenocarcinoma usually signifies advanced-stage disease, with the occurrence of nodal metastasis and pancreatic invasion [5]. Although our patient’s tumour featured poorly-differentiated signet-ring cells, there was no lymph node involvement at presentation. Indeed, prognosis seems closely related to the extent of neural invasion and nodal metastasis at the time of surgery [3]. Nevertheless, prognosis is difficult to ascertain in ampullary SRCC, compared to ampullary adenocarcinoma, owing to the limited number of reports so far.

The majority of patients in previous cases of ampullary SRCC underwent pancreaticoduodenectomy, occasionally with extended lymphadenectomy and/or partial gastrectomy. This radical approach facilitates lymph node dissection in advanced disease states, but a pylorus-preserving technique, which has been utilised in three previous cases of ampullary SRCC [9, 13, 14], may be more applicable in early disease, where curability is balanced by a more moderate resection. Although currently a controversial strategy, pylorus-preserving pancreaticoduodenectomy for suspected peri-ampullary malignancy has been shown to be comparable to classical Whipple’s operation, in terms of operating time, intra-operative blood loss, complications such as delayed gastric emptying, as well as disease-free survival [15, 16]. Nevertheless, our patient recovered in an uneventful manner following Whipple’s resection. Interestingly, one group successfully performed ampullectomy using a transduodenal approach for ampullary SRCC, with no evidence of disease at twelve month follow-up; this technique has not been utilised since. Endoscopic stent insertion has also been reported as a conservative treatment [17].

We performed a classical Whipple’s procedure to maximise curative potential, since pre-operative histological diagnosis was not available. On account of negative resection margins and absence of nodal involvement, post-operative chemotherapy was not deemed necessary.

Chemoradiotherapy based on 5-fluorouracil has been employed as an adjunctive treatment modality following curative resection of ampullary adenocarcinomas. However, there is debate as to whether this actually affords a statistically significant survival benefit, since many patients develop metastatic disease [18, 19]. Presently, no established adjuvant chemotherapeutic regimen exists specifically for ampullary SRCC, although documented anti-neoplastic agents have been used in five cases.

Nabeshima et al. treated a 49-year-old male patient with ampullary SRCC and secondary bone metastasis (pT3NxM1) with 5-fluorouracil and leucovorin, reporting increased survival and quality of life [8]. Another 45-year-old male patient with pT4pN1pMX ampullary SRCC received six months of adjuvant gemcitabine and oxaliplatin, but three months subsequently developed leptomeningeal metastases, with a poor response to intrathecal methotrexate [9]. In Kim et al.’s report, a 47-year-old male patient, found to have multiple nodal metastases at operation, was conservatively managed with biliary stenting and titanium silicate/cisplatin chemotherapy, but died one year post-diagnosis [20]. In contrast, Lesquereux-Martínez et al. treated a 78-year-old female patient with ampullary SRCC and minimal neoplastic nodal infiltration (1/21 lymph nodes) with adjuvant gemcitabine, finding her disease-free at 14 months [21]. In Douadi et al.’s report, a 55-year-old male patient with pT3N0M0 disease received six cycles of adjuvant gemcitabine/cisplatin, without disease recurrence at eight months [22].

Thus, adjuvant chemotherapy may be appropriate in the treatment of ampullary SRCC associated with loco-regional metastasis. However, its role in node-negative and distant metastatic disease remains as yet undetermined and, from the case reports evaluated, consensus regarding the optimum chemotherapeutic regimen is lacking.

In conclusion, we here report a very rare case of poorly-differentiated ampullary carcinoma with signet-ring features, but without distant metastatic disease. We believe the tumour arose from pancreatobiliary epithelium, according to immunohistochemical staining patterns. Whilst pancreaticoduodenectomy can afford a good outcome in early, node-negative SRCC, the long-term prognosis remains uncertain.

Received October 26^th, 2012 – Accepted November 27^th, 2012

Key words Ampulla of Vater; Carcinoma, Signet Ring Cell; Pancreas

Abbreviations SRCC: signet-ring cell carcinoma

Conflicts of interest The authors declare they have no conflicts of interest to disclose

Source of funding No external sources of funding

Correspondence
Metesh Nalin Acharya
Department of Surgery and Cancer
Imperial College London
Hammersmith Hospital Campus
London, W12 0HS
United Kingdom
Phone: +44-(0)20.8383.3937
Fax: +44-(0)20.8383.3212
E-mail: metesh.acharya@doctors.org.uk

References

1. Gao JM, Tang SS, Fu W, Fan R. Signet-ring cell carcinoma of the ampulla of Vater: contrast-enhanced ultrasound findings. World J Gastroenterol. 2009;15:888-91. [PMID: 19230055]

2. Sekoguchi T, Mizumoto R. Clinicopathological study of papilla of Vater. Geka Chiryo. 1979;41:1-5.

3. Gheza F, Ceryi E, Pulcini G, Villanacci V, Giulini SM, Schiavo-Lena M, Ferrari AB, et al. Signet ring cell carcinoma of the ampulla of Vater: demonstration of pancreatobiliary origin. Pancreas. 2011;40:791-3. [PMID: 21673543]

4. Li L, Chen QH, Sullivan JD, Breuer FU. Signet-ring cell carcinoma of the ampulla of Vater. Ann Clin Lab Sci. 2004;34:471-5. [PMID: 15648791]

5. Akatsu T, Aiura K, Takahashi S, Kameyama K, Kitajima M, Kitagawa Y. Signet-ring cell carcinoma of the ampulla of Vater : report of a case. Surg Today. 2007;37:1110-4. [PMID: 18030577]

6. Purohit RC, Kant K, Bhargava N, Kothari N, Purohit V. Signet ring cell carcinoma of ampulla of Vater in a young adult. Indian J Gastroenterol. 2005;24:222-3. [PMID: 16361773]

7. Taş A, Ozer E, Köklü S, Kocak E. Signet ring cell carcinoma of the ampulla of vater: rare cause of acute pancreatitis. Scand J Gastroenterol. 2011;46:126-7. [PMID: 20950208]

8. Nabeshima S, Kishihara Y, Nabeshima A, Yamaga S, Kinjo M, Kashiwagi S, Hayashi J. Poorly differentiated adenocarcinoma with signet-ring cells of the Vater’s ampulla, without jaundice but with disseminated carcinomatosis. Fukuoka Igaku Zasshi. 2003;94:235-40. [PMID: 14509231]

9. Paplomata E, Wilfong L. Signet ring cell carcinoma of the ampulla of Vater with leptomeningeal metastases: a case report. J Clin Oncol. 2011;29:e627-9. [PMID: 21606434]

10. Ishibashi Y, Ito Y, Omori K, Wakabayashi K. Signet ring cell carcinoma of the ampulla of Vater. A case report. JOP. 2009;10:690-3. [PMID: 19890196]

11. Ramia JM, Mansilla A, Villar J, Muffak K, Garrote D, Ferron JA. Signet-ring cell carcinoma of the Vater’s ampulla. JOP. 2004;5:495-7. [PMID: 15536289]

12. Eriguchi N, Aoyagi S, Jimi A. Signet-ring cell carcinoma of the ampulla of Vater: report of a case. Surg Today. 2003;33:467-9. [PMID: 12768376]

13.  Hara T, Kawashima H, Ishigooka M, Kashiyama M, Takanahi S, Hosokawa Y. Signet-ring-cell carcinoma of the ampulla of Vater: a case report. Hepatogastroenterology. 2002;49:561-3. [PMID:11995497]

14.  Valeri S, Caricato M, Ripetti V, Crucitti P, Ausania F, Garberini A, et al. Signet-ring cell carcinoma of the Vater’s ampulla: report of a clinical case. Suppl Tumori. 2005;4:S61. [PMID: 16437905]

15. Tran KT, Smeenk HG, van Eijck CH, Kazemier G, Hop WC, Greve JC, Terpstra OT et al. Pylorus-preserving pancreaticoduodenectomy versus standard Whipple procedure: a prospective, randomized, multicenter analysis of 170 patients with pancreatic and periampullary tumours. Ann Surg. 2004;240:738-45. [PMID: 15492552]

16. Diener MK, Fitzmaurice C, Schwarzer G, Seiler CM, Antes G, Knaebel HP, Büchler MW. Pylorus-preserving pancreaticoduodenectomy (pp Whiple) versus pancreaticoduodenectomy (classic Whipple) for surgical treatment of periampullary and pancreatic carcinoma. Cochrane Database Syst Rev. 2011 May 11;(5):CD006053. [PMID 21563148]

17. Terada T. Primary signet-ring cell carcinoma of the ampulla of Vater: a case report with an immunohistochemical study. Appl Immunohistochem Mol Morphol. 2012;20:427-8. [PMID 22710820]

18.  Zhou J, Hsu CC, Winter JM, Pawlik TM, Laheru D, Hughes MA, et al. Adjuvant chemoradiation versus surgery alone for adenocarcinoma of the ampulla of Vater. Radiother Oncol. 2009;92:244-8. [PMID 19541379]

19. Narang AK, Miller RC, Hsu CC, Bhatia S, Pawlik TM, Laheru D, et al. Evaluation of adjuvant chemoradiation therapy for ampullary adenocarcinoma: the Johns Hopkins Hospital-Mayo Clinic collaborative study. Radiat Oncol. 2011;28:126. [PMID 21951377]

20. Kim DI, Park SW, Lee GS, Jung GY, Jung HJ, Moon HC, et al. A Case of Signet-ring Cell Carcinoma of the Ampulla of Vater. Korean J Gastroint Endosc. 2010;41:251-4.

21. Lesquereux-Martínez L, Fernández-Pérez A, Bustamante-Montalvo M. Signet ring cell adenocarcinoma of the ampulla of Vater: A rare pathology. Rev Esp Enferm Dig. 2012;104:501-2. [PMID 23130863]

22. Daoudi K, El Haoudi K, Bouyahia N, Benlemlih A, Arifi S, Mellas N, et al. Signet Ring Cell Carcinoma of the Vater’s Ampulla: A Very Rare Malignancy. Case Rep Oncol Med. 2012;2012:402798. [PMID 23056971]

23. Gardner HA, Matthews J, Ciano PS. A signet-ring cell carcinoma of the ampulla of Vater. Arch Pathol Lab Med. 1990;114:1071-2. [PMID 2171451]

24. Arnal Monreal FM, Lorenzo Patiño MJ, Sacristán F, Ghanimé Saide G. Signet ring cell carcinoma of the Vater’s ampulla. Rev Esp Enferm Dig. 1994;85:391–3. [PMID 8049111]

25. Casella R, Rittmann WW, Meier R, Wegmann W, Widmer MK, Hunger T. Signet ring cell carcinoma of Vater’s papilla: a very rare malignancy. Helv Chir Acta. 1994;60:987–90. [PMID 7876027]

26. Tseng LJ, Jao YT, Mo LR. Signet ring cell carcinoma of major papilla. Gastrointest Endosc. 2002;56:733. [PMID 12397285]

27. Fang CL, Chu JS, Hsieh MC, Wu MS. Signet-ring cell carcinoma of the ampulla of Vater. J Formos Med Assoc. 2004;103:793–6. [PMID 15490032]

28. Zhou H, Schaefer N, Wolff M, Fischer HP. Carcinoma of the ampulla of Vater: comparative histologic/immunohistochemical classification and follow-up. Am J Surg Pathol. 2004;28:875-82. [PMID 15223956]

29. Bloomston M, Walker M, Frankel WL. Radical resection in signet ring carcinoma of the ampulla of Vater: report of an 11-year survivor. Am Surg. 2006;72:193-5. [PMID 16536256]

30. García AB, Arranz EM, Sanz RR, Serrano EM, Arranz MD, Sanz-Agero PG, et al. Signet ring cell carcinoma of the ampulla of Vater. Gastroenterol Hepatol. 2011;34:141-6. [PMID 21376425]

31. Maekawa H, Sakurada M, Orita H, Sato K. Signet-ring cell carcinoma co-existing with adenocarcinoma of the ampulla of vater. A case report. JOP. 2011;12:162-6. [PMID 23186645]
