CASE REPORT
JOP. J Pancreas (Online) 2011 May 6; 12(3):283-286.
Malignant Pancreatic Extra-Gastrointestinal Stromal Tumor Diagnosed by Ultrasound Guided Fine Needle Aspiration Cytology. A Case Report with a Review of the Literature
Ram Nawal Rao1, Mukul Vij1, Nidhi Singla1, Ashok Kumar2
Departments of 1Pathology and 2Surgical Gastroenterology, Sanjay Gandhi Postgraduate Institute of Medical Sciences. Lucknow, UP, India
ABSTRACT
Context Pancreatic extra-gastrointestinal stromal tumors are extremely uncommon neoplasm. To the best of our knowledge, only eleven cases have been reported in the literature. All the case reports published mostly involve diagnoses made on surgical pathology. Case report A 40-year-old male patient presented with asthenia, mild abdominal pain, severe anemia and weight loss. Contrast-enhanced computed tomography of the abdomen revealed a heterogeneously enhancing mass (6.5x6.0 cm) in the body and head of the pancreas. Ultrasound-guided fine needle aspiration (US-FNA) was performed on the mass of the pancreas before a pancreaticoduodenectomy. A cytological diagnosis of pancreatic malignant mesenchymal neoplasm was made. The final diagnosis of primary pancreatic extra-gastrointestinal stromal tumor was confirmed by histopathological examination and immunohistochemical findings (CD117 positivity). This case was diagnosed by percutaneous transabdominal ultrasound, rather than endoscopic ultrasound-guided fine needle aspiration (EUS-FNA) which had been used in three previous cases. Conclusion We report a very unusual case of pancreatic extra-gastrointestinal stromal tumor which was diagnosed by US-FNA cytology. Although this is uncommon in the pancreas, extra-gastrointestinal stromal tumors should be considered in the differential diagnosis of solid and cystic pancreatic masses on cytology.
INTRODUCTION
Gastrointestinal stromal tumors (GISTs) are mesenchymal tumors predominantly occurring in the stomach and small intestine. GISTs originate from the soft tissue of the abdomen and retroperitoneum but display no connection to the wall or the serosal surface of the viscera. They are considered to arise from various anatomic sites, such as the omentum, mesentery, retroperitoneum and gall bladder [1, 2]. Primary extra-gastrointestinal stromal tumors (E-GISTs) arising in the pancreas are extremely rare, and only eleven cases have been reported in the literature, eight of which have been diagnosed by histopathology and three by cytology [3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13]. We report the fourth case of primary pancreatic extra-gastrointestinal stromal tumor with metastases to the liver, and present a review of literature.
CASE REPORT
A 40-year-old male patient presented with asthenia, mild abdominal pain, low grade fever and severe anemia. It was associated with loss of appetite and a 2 kg weight loss over three months. No lump was palpable in the epigastrium on abdominal examination. Routine laboratory investigations were within normal limits except for severe anemia (hemoglobin: 3.5 g/dL; reference range: 12-15 g/dL).
Ultrasonographic examination of the abdomen showed a solid mass in the head and the body of the pancreas. The mass did not invade or compress any vascular structures on CT or ultrasonography. A contrast-enhanced computed tomography of the abdomen revealed a heterogeneously enhancing mass (mostly solid) in the body and head of the pancreas measuring 6.5x6.0 cm. The mass did not communicate with the main pancreatic duct. There was no evidence of ascites or lymphadenopathy.
Cytological Features
Smears from the pancreatic mass showed atypical spindle-shaped cells arranged in small clusters and sheets with a myxoid background (Figure 1). The patient developed liver nodules within 24 months. Ultrasound-guided fine needle aspiration (US-FNA) from the liver nodule was performed which also showed dyscohesive groups of atypical spindle-shaped cells with a myxoid background, consistent with metastatic E-GISTs.
Figure 1. FNA smear from the pancreatic mass showing clusters of atypical spindle-shaped cells with a myxoid background (May-Grunnwald Giemsa staining (MGG), x200). |
Gross Features
A pancreaticoduodenectomy specimen showed a large fleshy tumor mass (6.5x6.0 cm) in the head and body of the pancreas, replacing most of the parenchyma. The cut surface showed a variegated solid mass (Figure 2).
Figure 2. Pancreaticoduodenectomy specimen showing a solid mass in the head and body of the pancreas measuring 6.5x6.0 cm with a variegated cut surface. |
Histopathological Examination
Sections from the pancreatic mass and the liver nodule showed sheets of spindle-shaped cells arranged in fascicles with a chronic inflammatory background (Figure 3). Brisk mitoses (more than 8-10/50 HPF) were also seen. On immunohistochemistry, the tumor cells were strongly positive for CD117 (Figure 4), CD34 and vimentin, and negative for SMA, desmin, S-100 and cytokeratin.
Figure 3. Sections from the pancreatic mass showing sheets of atypical spindle-shaped cells arranged in fascicles, and chronic inflammatory cells with a normal pancreas at one end (H&E, x200). |
Figure 4. Tumor cells showing strong CD117 positivity on immunohistochemistry (x200). |
DISCUSSION
Pancreatic gastrointestinal stromal tumors are very rare neoplastic lesions. GISTs reported outside the gastrointestinal tract as apparent primary tumors are designated as extra-gastrointestinal stromal tumors (E-GISTs). A primary localization in the pancreas has rarely been reported on cytology. The clinical symptoms include abdominal pain, early satiety, flatulence, ileus, bleeding, anemia, and weight loss. It can be diagnosed incidentally by radiologic imaging [14]. They are usually asymptomatic depending on the location, size of the tumor and the lack of mucosal involvement [7]. GISTs originate from the interstitial cells of Cajal, which are the pacemaker cells of the gastrointestinal tract. These cells express c-kit proteins (CD117), CD34, and vimentin [4]. On immunohistochemistry, eight of the previous eleven reported cases demonstrated intense immunoreactivity for CD117 and CD34 [3, 7, 8, 9, 10, 11, 12, 13] whereas three cases showed negative staining for CD117 [4, 5, 6].
Most pancreatic masses are adenocarcinomas; however, clinicians should be aware of other possibilities which have different (and usually better) treatment and prognoses. The cytologic differential diagnosis for these spindle cell proliferations includes leiomyoma, schwannoma, fibromatosis, inflammatory fibroid polyps, and gastrointestinal muscularis sampling [8]. Immunohistochemistry demonstrating CD117 positivity confirms the diagnosis of GISTs. In the literature, cases of fibromatosis have been reported to react with antibodies directed against CD117, although this does not typically involve the pancreas [14]. GISTs primarily occur within the luminal gastrointestinal tract, but practitioners should be aware that they can arise from outside the gastrointestinal tract. E-GISTs are rare and are found in the omentum, mesentery, retroperitoneum or other intra-abdominal sites [15]. The first case of pancreatic E-GISTs diagnosed by endoscopic ultrasound-guided (EUS-FNA) was in a 47-year-old male having self-limited episodes of nausea and bilious vomiting with no other significant gastrointestinal symptoms or constitutional features [8].
Harindhanavudhi et al. [9] diagnosed the second case of a pancreatic E-GIST by means of EUS-FNA. The patient refused surgery but cyst drainage and a cystojejunostomy were carried out. They presented with severe anemia due to cyst formation and hemorrhage within the E-GIST.
Saif et al. [10] reported the third case of a pancreatic E-GIST by EUS-FNA and te patient developed liver metastasis within 6 months with an aggressive outcome.
We herein report the fourth case of a high risk pancreatic E-GIST which was diagosed by US-FNA. The smears showed clusters of atypical spindle-shaped cells displaying moderately pleomorphic hyperchromatic elongated nuclei and variable amounts of cytoplasm with a myxoid background. A cytological diagnosis of malignant mesenchymal neoplasm of the pancreas was reached and it was confirmed by histopathology and immunohistochemistry with a strong positivity of CD117, consistent with pancreatic E-GIST. Our patient developed liver metastasis within 24 months and also presented with severe anemia without cyst formations which indicates severe anemia may also be associated with solid-cystic pancreatic E-GISTs.
The comparison of clinicopathological features and treatment outcomes of previously described pancreatic E-GISTs by EUS-FNA, including the present case, are shown in Table 1.
Table 1. Pancreatic E-GIST cases diagnosed by ultrasound- (US) or endoscopic ultrasound- (EUS) guided fine needle aspiration (FNA). |
|||||||
Case |
Author |
Age |
Presentation |
Location |
Pathology |
Treatment |
Follow-up |
#1 |
Yan et al., 2008 (EUS-FNA) |
47 years Male |
Nausea and vomiting |
Uncinate process |
Solid mass with necrotic foci of 2.4x2.1 cm Mitotic count: 3/50 HPF IHC: CD117 (+), SMA (-), S-100 (-) |
Not available |
Not available |
#2 |
Haridhanavudi et al., 2009 (EUS-FNA) |
63 years Female |
Fatigue and weakness |
Body |
Hemorrhagic cyst of 16x11 cm Mitotic count: less than 5/50 HPF IHC: CD117 (+), CD34 (+), SMA (+), MSA (+) |
Cyst drainage and cystojejunostomy. Patient refused surgery and imatinib therapy |
Not available |
#3 |
Saif et al., 2010 (EUS-FNA) |
31 years Male |
Abdominal pain, fatigue, weight loss, anemia hematemesis |
Head with liver space-occupying lesion |
Hypervascular mass of 5.1x4.2x5.6 cm Liver mass of 9x7cm Mitotic count: 24/25 HPF IHC: CD117(+) |
Whipple procedure, imatinib therapy |
Developed liver metastasis in 9 months |
#4 |
Present case, 2011 (US-FNA) |
40 years Male |
Abdominal pain, weight loss |
Body and head with liver space-occupying lesion |
Solid mass of 6.5x5.0 cm Liver mass of 9x7 cm Mitotic count: 8-10/50 HPF IHC: CD117 (+), CD34 (+), SMA (-), S-100 (-), CK (-) |
Whipple procedure, imatinib therapy |
Developed liver metastasis in 24 months. No evidence of disease at 30 months |
(+): positive; (-): negative; CK: cytokeratin; IHC: immunohistochemistry; HPF: high power field; MSA: muscle specific actin; SMA: smooth muscle actin |
There was a distinct female predominance, age ranging from 38 to 72 years including all surgical pathological cases (mean age 55 years). The majority occurred in the body and tail of the pancreas with an average size of 12 cm. Seven of the eleven cases had symptoms of abdominal pain with or without fatigue and weight loss. The mitotic rate in most of these tumors was low on histopathology except in three cases (more than 120/50 HPF [3], 24/25 HPF [10] and more than 6-8/50 HPF [12]). One patient had a history of rapid recurrence of the disease with peritoneal and nodal metastasis following surgery and imatinib therapy [3].
In our case report, the mitotic figures were 8-10/50 HPF. The patient is on regular 6-month follow- ups. Computed tomography was carried out and showed liver metastasis within 24 months of surgical resection. The patient is well and on imatinib therapy (400 mg bid) after a partial hepectomy.
We concluded that these rare cases of pancreatic extra-gastrointestinal stromal tumors can be diagnosed by US-FNA cytology. Although this is rare in the pancreas, extra-gastrointestinal stromal tumors should be considered in the differential diagnosis of solid and cystic pancreatic masses on cytology.
Received February 21st, 2011 - Accepted April 5th, 2011
Key words Adenocarcinoma; Gastrointestinal Stromal Tumors; Liver; Pancreatic Neoplasms; Proto-Oncogene Proteins c-kit
Abbreviations E-GIST: extra-gastrointestinal stromal tumor; GIST: gastrointestinal stromal tumor
Conflict of interest The authors have no potential conflicts of interest
Correspondence
Ram
Nawal Rao
Cytology and Histopathology Division
Pathology Department
Sanjay Gandhi Postgraduate Institute of Medical Sciences
Raibarely Road
Lucknow 226011, UP
India
Mobile: +91-800.490.4564
Fax: +91-0522.266.8017; +91-0522.266.8078
E-mail: rnrao@sgpgi.ac.in; rnawalrao@gmail.com
References
1. Ortiz-Hidalgo C, de Leon Bojorge B, Albores-Saavedra J. Stromal tumor of the gallbladder with phenotype of interstitial cells of Cajal: a previously unrecognized neoplasm. Am J Surg Pathol 2000; 24:1420-3. [PMID 11023105]
2. Weiss SW, Goldblum JR. Extra gastrointestinal stromal tumors. In: Enzinger and Weiss's Soft Tissue Tumors; 5th Ed. Mosby Elesevier, 2008:565-79. [ISBN 978-0-323-04628-2]
3. Neto MR, Machuca TN, Pinho RV, Yuasa LD, Bleggi-Torres LF. Gastrointestinal stromal tumor: report of two unusual cases. Virchows Arch 2004; 444:594-6. [PMID 15118853]
4. Yamaura K, Kato K, Miyazawa M, Haba Y, Muramatsu A, Miyata K, Koide N. Stromal tumor of the pancreas with expression of c-kit protein: report of a case. J Gastroenterol Hepatol 2004; 19:467-70. [PMID 15012791]
5. Krska Z, Pesková M, Povýsil C, Horejs J, Sedlácková E, Kudrnová Z. GIST of pancreas. Prague Med Rep 2005; 106:201-8. [PMID 16315768]
6. Daum O, Klecka J, Ferda J, Treska V, Vanecek T, Sima R, et al. Gastrointestinal stromal tumor of the pancreas: Case report with documentation of KIT gene mutation. Virchows Arch 2005; 446:470-2. [PMID 15756592]
7. Showalter SL, Lloyd JM, Glassman DT, Berger AC. Extra-gastrointestinal stromal tumor of the pancreas: case report and a review of the literature. Arch Surg 2008; 143:305-8. [PMID 18347279]
8. Yan B M, Pai R K, Dam J V. Diagnosis of pancreatic gastrointestinal stromal tumor by EUS guided FNA. JOP. J Pancreas (Online) 2008; 9:192-6. [PMID 18326928]
9. Harindhanavudhi T, Tanawuttiwat T, Pyle J, Silva R. Extra-gastrointestinal stromal tumor presenting as hemorrhagic pancreatic cyst diagnosed by EUS-FNA. JOP. J Pancreas (Online) 2009; 10:189-91. [PMID 19287116]
10. Saif MW, Hotchkiss S, Kaley K. Gastrointestinal stromal tumors of the pancreas. JOP. J Pancreas (Online) 2010; 11:405-6. [PMID 20601822]
11. Trabelsi A, Yacoub-Abid L B, Mtimet A, Ben Abdelkrim S, Hammedi F, Ben Ali A, Mokni M. Gastrointestinal stromal tumor of the pancreas: A case report and review of the literature. North Am J Med Sci 2009; 1:324-6.
12. Padhi S, Kongara R, Uppin SG, Uppin MS, Prayaga AK, Challa S, et al. Extragastrointestinal stromal tumor arising in the pancreas: a case report with a review of the literature. JOP. J Pancreas (Online) 2010; 11:244-8. [PMID 20442520]
13. Yang F, Jin C, Fu D, Ni Q. Extra-gastrointestinal stromal tumor of the pancreas: Clinical characteristics, diagnosis, treatment, and outcome. J Surg Oncol 2011; 103:739-40. [PMID 21240986]
14. Miettinen M. Are desmoid tumors kit positive? Am J Surg Pathol 2001; 25:549-50. [PMID 11257638]
15. Cichoz-Lach H, Kasztelan-Szczerbińska B, Słomka M. Gastrointestinal stromal tumors: epidemiology, clinical picture, diagnosis, prognosis and treatment. Pol Arch Med Wewn 2008; 118:216-21. [PMID 18575421]
