CASE REPORT



JOP. J Pancreas (Online) 2011 Mar 9; 12(2):152-154.





Heterotopic Pancreatic Tissue Located in the Gallbladder Wall. A Case Report





Hasan Gucer1, Pelin Bagci1, Esra Zeynep Coskunoglu2, Cetin Karadag3





1Department of Pathology, Rize University Medical School. Rize, Turkey. 2Department of Pathology, Rize Education and Research Hospital. Rize, Turkey. 3Department of General Surgery, Unye State Hospital. Ordu, Turkey





ABSTRACT

Context Heterotopia of the pancreas can be defined as the presence of pancreatic tissue in an abnormal location without any continuity with the main body of the pancreas. Heterotopic pancreatic tissue located in the gallbladder is a rare entity. Despite being a congenital condition, it takes years for heterotopic pancreas to become symptomatic. Case report An 80-year-old male patient presented to our hospital with a two-week history of abdominal pain, nausea and vomiting aggravated after meals. Abdominal ultrasonography revealed minimal wall edema and small grain-sized gallstones in the gallbladder. The patient was hospitalized and laparoscopic cholecystectomy was performed for acute cholecystitis. Pathologic examination showed a 6 mm nodular mass of pancreatic tissue in the gallbladder wall, comprised mainly of ductal and acinic structures and a few endocrine cells. Conclusion We found this case of pancreatic heterotopia worth reporting because of its rare incidence.





INTRODUCTION

Heterotopia of the pancreas, also called pancreatic choristoma, is defined as pancreatic tissue in an abnormal location without any vascular, neuronal or anatomical continuity with the main body of the pancreas [1]. Heterotopic pancreas tissue is commonly found in the stomach, duodenum, proximal jejunum and Meckel’s diverticulum, but is rarely seen in the ileum, gallbladder, bile ducts, splenic hilum, umbilicus and liver [2, 3, 4].

In this report, we present a case of heterotopic pancreas located in the gallbladder with clinical findings of acute cholecystitis.

CASE REPORT

An eighty-year-old male presented to the Department of General Surgery with nausea, vomiting, abdominal distension and abdominal pain of 2 months duration which was aggravated after meals. On physical examination, the right upper abdomen was tender with a positive Murphy’s sign, but there was no defense or rebound. Abdominal ultrasound revealed biliary sludge in the lumen of the gallbladder and minimal wall edema. His laboratory data revealed a total bilirubin of 4 mg/dL (reference range: 0.2-1.2 mg/dL), a direct bilirubin of 3.5 mg/dL (reference range: 0-0.5 mg/dL), alkaline phosphatase equal to 425 U/L (reference range: 40-150 U/L), AST equal to 389 U/L (reference range: 5-34 U/L), ALT equal to 489 U/L (reference range: 0-55 U/L), GGT equal to 682 U/L (reference range: 9-64 U/L) and amylase equal to 166 U/L (reference range: 25-125 U/L). Laparoscopic cholecystectomy was carried out with a preoperative diagnosis of acute cholecystitis.

At macroscopic examination, the gallbladder was 25 g in weight and 7.5x5.5x0.3 cm in diameter. A 6 mm, solid intramural nodule was seen at the corpus. The cut section of the nodule was straw-colored, hard and had focal hemorrhagic areas (Figure 1). Thick biliary sludge was seen in the lumen, but there were no stones.





Figure 1. Nodular lesion (black arrow) in the subserosal adipose layer of the gallbladder with a straw-colored cut surface showing central hemorrhage. The gallbladder mucosa is shown with the white arrow.





Microscopic examination revealed aberrant pancreatic tissue consisting of acini, intra and interlobular ducts and some chromogranin A and few synaptophysin expressing islet cells (Figures 2, 3, and 4). No direct connection with the gallbladder lumen was observed. A chronic inflammatory reaction with some eosinophils was also seen at subepithelial areas.





Figure 2. Intramural and subserosal ectopic pancreatic tissue. Gallbladder mucosa can be seen at the upper left corner (H&E: a. x40; b. x100).





Figure 3. Ductal and acinic structures (H&E x400).





Figure 4. a. Synaptophysin reactivity in endocrine cells (Synaptophysin x200). b. Chromogranin A reactivity in endocrine cells (Chromogranin A x200).





All symptoms disappeared following cholecystectomy and the patient recovered completely.

DISCUSSION

As stated by Beltran and Barria [1], Schultz first described heterotopic pancreas in 1727 and Klob reported the first histopathological confirmation of heterotopic pancreas in 1859 [5]. About 30 cases of heterotopic pancreas in the gallbladder have been reported worldwide in a review of the literature up to the present [6].

The reported incidence of heterotopic pancreas in the gastrointestinal tract ranged from 0.55% to 13.7% in autoptic series, and 0.2% in laparotomy [2, 7, 8]. Heterotopic pancreas can affect all ages, and men are usually affected three times more than women [6]. However, there is a higher incidence of female patients in heterotopic pancreas of the gallbladder cases [8]. In our case, the patient was a male.

The majority of cases are asymptomatic; but it can be associated with obstruction of the bile duct, cholelithiasis, acute or chronic pancreatitis, hyperinsulinism, intussusception and gastrointestinal hemorrhage. In addition, heterotopic pancreatic tissue is prone to different pathologic changes, such as cyst or abscess formation, acute pancreatitis and calcification [1, 2, 3, 6, 7, 8]. In our case, the ectopic tissue caused chronic cholecystitis. Most cases of pancreatic heterotopia have biologically benign behavior; however, only a few reports have described benign and malignant neoplastic changes [9, 10]. There were no metaplastic or neoplastic changes in our case.

Preoperative diagnosis is rarely possible because it is a very uncommon pathologic entity and is therefore not considered in the differential diagnosis, either clinically or radiologically [11].

Macroscopically, these lesions are usually detected incidentally as well-circumscribed, firm, round, single, yellow nodules. Their size can vary from several millimeters to centimeters [1, 2, 3, 6, 7, 8]. Fifty percent of heterotopic pancreatic tissue found in the gallbladder is located in the neck [7]. The lesion was located at the corpus in our case. It can be located in the submucosa, muscularis propria or subserosa [1, 2, 3, 6, 7, 8].

Microscopically, ectopic pancreas has been classified into three types by von Heinrich (Table 1) [9, 12]. Our case was considered to be a type 1 ectopic pancreas, based on Heinrich classification.





Table 1. Heinrich classification of ectopic pancreas [9, 12].

Type 1

Ectopic tissue with acini, ducts and islets of Langerhans.

Type 2

Ectopic tissue with incomplete or lobular arrangement (only a few acini and multiple ducts). Endocrine elements are absent.

Type 3

Ectopic tissue of proliferating ducts (so-called adenomyoma). Both exocrine acini and endocrine elements are lacking.





The origin of heterotopic pancreatic tissue is controversial but two theories have been proposed. The most widely accepted theory is that heterotopic pancreas is formed from a lateral budding of the rudimentary pancreatic duct while penetrating the intestinal wall and is carried by the longitudinal growth of the intestines. The other theory suggests that the pancreatic tissue is separated from the main pancreas during embryonic rotation [7, 8]. A recent theory states that abnormalities in the notch signaling system during embryogenesis may contribute to heterotopic pancreatic tissue in the gallbladder [7].

Heterotopic pancreas located in the gallbladder wall is an uncommon lesion which is most often detected incidentally and may be associated with gallbladder symptomatology. Although not proven, this rare condition may have the potential of developing into a malignancy.

We found this case of pancreatic heterotopia worth reporting because of its rarity and its association with cholecystitis symptomatology.





Received December 31st, 2010 - Accepted January 5th, 2011

Key words Choristoma; Gallbladder; Pancreas

Conflicts of interest The authors have no potential conflicts of interest

Correspondence
Hasan Gucer
Rize Universitesi Tip Fakultesi
Patoloji Anabilim Dali
Sehitler Street No: 74 Islampasa
53100 Rize
Turkey
Phone: +90-464.213.0492
Fax: +90-464.214.2812
E-mail: hasan_gucer@yahoo.com





References

1. Beltran MA, Barria C. Heterotopic pancreas in the gallbladder. The importance of an uncommon condition. Pancreas 2007; 34:488-90. [PMID 17446856]

2. Inceoglu R, Dosluoglu HH, Kullu S, Ahiskali R, Doslu FA. An unusual cause of hydropic gallbladder and biliary colic--heterotopic pancreatic tissue in the cystic duct: report of a case and review of the literature. Surg Today 1993; 23:532-4. [PMID 8358197]

3. Murakami M, Tsutsumi Y. Aberrant pancreatic tissue accompanied by heterotopic gastric mucosa in the gall-bladder. Pathol Int 1999; 49:580-2. [PMID 10469405]

4. Terada T, Nakanuma Y, Kakita A. Pathologic observations of intrahepatic peribiliary glands in 1000 consecutive autopsy livers. Heterotopic pancreas in the liver. Gastroenterology 1990; 98:1333-7. [PMID 2182371]

5. Klob J. Pancreas accessorium. Zeitschrift der Kaiserl. Königl. Gesellschaft der Aerzte zu Wien 1859; 15:732.

6. Al-Shraim M, Rabie ME, Elhakeem H, Kandeel A, Shah MT, Jamil S. Pancreatic heterotopia in the gallbladder associated with chronic cholecystitis: a rare combination. JOP. J Pancreas (Online) 2010; 11:464-6. [PMID 20818117]

7. Weppner JL, Wilson MR, Ricca R, Lucha PA Jr. Heterotopic pancreatic tissue obstructing the gallbladder neck: A case report. JOP. J Pancreas (Online) 2009; 10:532-4. [PMID 19734631]

8. Elpek GO, Bozova S, Küpesiz GY, Oğüş M. An unusual cause of cholecystitis: Heterotopic pancreatic tissue in the gallbladder. World J Gastroenterol 2007; 13:313-5. [PMID 17226916]

9. Ogata M, Chihara N, Matsunobu T, Koizumi M, Yoshino M, Shioya T, et al. A case of intra-abdominal endocrine tumor possibly arising from an ectopic pancreas. J Nippon Med Sch 2007; 74:168-72. [PMID 17507794]

10. Chetty R, Weinreb I. Gastric neuroendocrine carcinoma arising from heterotopic pancreatic tissue. J Clin Pathol 2004; 57:314-7. [PMID 14990608]

11. Shiwani MH, Gosling J. Heterotopic pancreas of the gallbladder associated with chronic cholecystitis. JOP. J Pancreas (Online) 2008; 9:30-2. [PMID 18182740]

12. von Heinrich H. Ein Beitrag zur Histologie des Sogen: akzessorischen Pankreas. Virchows Arch A Pathol Anat Histopathol 1909;198:392-401.
