ORIGINAL ARTICLE
JOP. J Pancreas (Online) 2010 Jan 8; 11(1):25-30.
Incidence and Management of Arterial Anomalies in Patients Undergoing Pancreaticoduodenectomy
Azhar Perwaiz, Amanjeet Singh, Tanveer Singh, Adarsh Chaudhary
Department of Surgical Gastroenterology, Sir Ganga Ram Hospital. New Delhi, India
ABSTRACT
Context Pancreaticoduodenectomy entails ligation of vascular arcades arising from the celiac and superior mesenteric arteries. These are known to have anatomical variations. Objective This study was aimed at analyzing the spectrum of arterial anomalies and their clinical impact on the procedure itself. Patients The study includes 200 consecutive patients who underwent a pancreaticoduodenectomy between September 2003 and May 2009 after excluding those having distant metastases or local unresectability. Main outcome measures The records of the patients were studied to assess the incidence of arterial anomalies and the operative complexities involved in a pancreaticoduodenectomy. Results Fifty-three patients (26.5%) had arterial anomalies. The complexity of the surgery was determined by the course of these arteries. The mean duration of surgery was 420±32.0 minutes in patients with arterial anomalies versus 370±38.5 minutes in those with a normal arterial anatomy (P= 0.005). Fifty-one out of 53 (96.2%) patients underwent pancreaticoduodenectomy with negative resection margins. The pancreaticoduodenectomy was abandoned in two cases due to patient- and tumor-related factors. Conclusion During pancreaticoduodenectomy, arterial anomalies can increase operative complexity but do not usually compromise the safety of the procedure or its oncological outcome.
INTRODUCTION
Pancreaticoduodenectomy (PD) is the standard surgical procedure for periampullary and pancreatic cancers. Ligation of the gastroduodenal artery and the pancreaticoduodenal arcade is necessary for its completion. The literature suggests that the normal pattern of hepatic artery anatomy is observed in 55 to 79% of patients [1, 2, 3, 4]. The majority of the anomalous arteries originate from branches of either the celiac or the superior mesenteric artery and they are likely to have an abnormal course. These arterial anomalies can usually be identified by routine preoperative computed tomography scans but, in some patients, they become obvious only during surgery. Arterial anomalies assume importance as there is a chance of inadvertently damaging them during the procedure, compromising the vascular supply of the liver. In addition there is the chance of oncological compromise in an attempt to protect the anomalous or replaced arteries. This study aims to analyze the consequences that these anomalous arteries have on PD itself.
PATIENTS AND METHODS
The study included 200 consecutive patients who had resectable disease and underwent a PD by a single surgical team in a tertiary care centre. Detailed information regarding these patients was maintained on a prospective database. Demography and patient characteristics were carefully recorded. Pancreatic protocol contrast-enhanced computed tomography (CECT) was used for the preoperative assessment of resectability.
The details of the arterial anatomy, their variations, especially the origin, course and relationship to the pancreatic head, and the operative complexities during the procedure were carefully recorded. Anatomy was considered to be normal when the celiac axis trifurcated into the left gastric artery, the splenic artery and the common hepatic artery. The common hepatic artery continued as a hepatic artery proper after giving origin to the gastroduodenal artery and then bifurcated into the right and left hepatic arteries. The right hepatic artery arising from a source other than the hepatic artery proper in the absence of a normally located right hepatic artery was termed as a replaced right hepatic artery. An accessory right hepatic artery was defined as a right hepatic artery arising from a source other than the hepatic artery proper in the presence of a normally located right hepatic artery. A similar definition was used for an accessory left hepatic artery and a replaced left hepatic artery. Trifurcation anomaly was defined to be the left hepatic artery, the right hepatic artery and the gastroduodenal artery originating from the common hepatic artery without giving origin to the trunk of the hepatic artery proper.
After removal of the specimen, the resection margins were marked with ink. In cases where the abnormal artery passed close to the tumor or the transection line, the area in the specimen was marked intraoperatively with silk suture. Apart from the arterial anomalies, tumor size, duration of surgery, blood loss and additional resections (arterial or venous resection and reconstruction, multivisceral resection) were also documented. The reason for not performing a PD was recorded in particular when an arterial anomaly was present. Confirmation of the diagnosis and the resection margin status were recorded from the histopathological report of the specimen. All postoperative complications were recorded. Death during the same hospital stay or within 30 days of surgery was considered as operative mortality.
The endpoints of the study were to analyze the incidences and the operative complexities due to these abnormal arteries and to compare the patients having a normal arterial anatomy with those patients who underwent a PD.
ETHICS
Informed consent was obtained in all cases. The protocol was in accordance with the declaration of Helsinki and was approved by the institutional review board.
STATISTICS
Data are reported as frequencies or mean±SD and ranges. The SPSS (version 17.0) software was used for data analysis. The Student t test was used to test significance for continuous variables and the Fisher’s exact test was used for categorical variables. Two-tailed P values less than 0.05 were considered significant.
RESULTS
Between September 2003 and May 2009, two hundred consecutive patients were included in the study. There were 148 (74.0%) males and 52 (26.0%) females with a mean age of 53.6±11.8 years (age range: 18-80 years). Pancreaticoduodenectomy was performed successfully in 198 (99.0%) patients. In the majority of cases, the indications were periampullary and pancreatic head cancer (Table 1). There were 53 (26.5%) arterial anomalies detected during the procedure. The spectrum of arterial anomalies was as shown in Table 2. Thirty-eight out of 53 (71.7%) anomalies were detected by preoperative CECT and the remaining 15 (28.3%) were found during the actual PD (Table 1). The course of these abnormal arteries varied according to their origin. All replaced right hepatic arteries or accessory right hepatic arteries arising from the superior mesenteric artery coursed posteriorly to the pancreatic parenchyma close to the head and uncinate process and then right posterolaterally to the common bile duct in the hepatoduodenal ligament. An anomalous artery from the gastroduodenal artery always looped down the superior border of the pancreas behind the neck and then coursed to the right or the left as a right or a left accessory or replaced hepatic artery respectively.
|
Table 1. Clinicopathological parameters of the patients (No. 200). |
|
|
Indications
for pancreaticoduodenectomy |
|
|
Detection
of anomalies |
|
|
Table 2. Spectrum of arterial anomalies during pancreaticoduodenectomy (No. 200). |
||
|
Anomalies |
Mitchel type [3] |
No. of cases |
|
Normal anatomy |
I |
147 (73.5%) |
|
Anomalous
arterial anatomy |
|
53 (26.5%) |
|
aLHA: accessory left hepatic artery; aRHA: accessory right hepatic artery; GDA: gastroduodenal artery; LHA: left hepatic artery; rCHA: replaced common hepatic artery; RHA: right hepatic artery; rLHA: replaced left hepatic artery; rRHA: replaced right hepatic artery; SMA: superior mesenteric artery |
||
Effect of Arterial Anomalies on the Technical Aspects of the Surgery
Minimal difficulty during PD occurred in 11 (20.8%) cases. Three patients had trifurcation anomalies and 8 patients with replaced left hepatic arteries from the left gastric artery. The anomalous artery was coursing away from the field of transection. Pancreaticoduodenectomy was performed in all of them. No alteration or deviation of the procedure was necessary.
Difficulty in removing the uncinate process and division of the common bile duct occurred in 35 (66.0%) cases. These were due to anomalous right hepatic arteries (accessory or replaced; Figure 1) arising from superior mesenteric artery. In one of these patients, the PD was abandoned. This patient had a replaced right hepatic artery arising from the superior mesenteric artery, encased by a 5.5 cm tumor arising from the head of the pancreas. Pancreaticoduodenectomy was technically possible with arterial reconstruction in this case, but it was abandoned due to the risk of a positive resection margin.
|
Figure 1. CT angiogram showing a replaced right hepatic artery arising from the superior mesenteric artery. CHA: common hepatic artery; GDA: gastroduodenal artery; LGA: left gastric artery; LHA: left hepatic artery; RHA: right hepatic artery; SMA: superior mesenteric artery |
|
|
Difficulty in transection at the neck of the pancreas occurred in 6 (11.3%) patients. There were 5 patients with anomalous arteries from the gastroduodenal artery (3 with an accessory right hepatic artery and 2 with an accessory left hepatic artery) and one patient with a replaced common hepatic artery from the superior mesenteric artery (Figure 2). Anomalous arteries from the gastroduodenal artery were closely associated with the posterosuperior surface at the level of the neck of the pancreas. Apart from the danger of injuring these arteries during pancreatic neck transection, there was difficulty in the ligation and division of the gastroduodenal artery and in creating a retropancreatic tunnel from the supraduodenal side. The gastroduodenal artery had to be dissected carefully, well below the origin of these abnormal arteries before it could be safely ligated and divided. One case was associated with an accessory left hepatic artery encased by a tumor; a PD with arterial division was performed without reconstruction as the test clamp of the anomalous artery showed preserved left hepatic arterial flow through the main left hepatic artery from the hepatic artery proper, which was confirmed by intraoperative Doppler ultrasound. In another patient, there was a replaced common hepatic artery arising from the superior mesenteric artery, coursing anteriorly to the neck of the pancreas, associated with a 3 cm mass in the head. The vessel was separated from the tumor; it was looped using sharp dissection and the PD was completed. The area in the specimen was marked with silk sutures and histopathology reported it to be negative for a tumor.
|
Figure 2. Replaced common hepatic artery (white arrow) coursing anteriorly to the pancreas. Celiac artery (black arrow) not giving origin to the common hepatic artery. |
|
|
The risk of compromising the hepatic arterial supply occurred in one (1.9%) patient. This 71-year-old patient had celiac artery stenosis (Figure 3), associated with a 6 cm mass in the head of the pancreas. The patient was known to have coronary artery disease. During surgery, it was found that the common hepatic artery from the celiac axis was small in size and the gastroduodenal artery was tortuous. A test clamp of the gastroduodenal artery led to the cessation of the flow in the right and left hepatic arteries. A prominent pancreaticoduodenal arterial arcade from the superior mesenteric artery was found coursing across the tumor and supplied the hepatic arteries through the gastroduodenal artery. All the major arteries (aorta, superior mesenteric artery and celiac axis) showed alterations due to atherosclerosis. The feasibility of PD with negative margins was remote and gastroduodenal artery reconstruction was not considered safe. Although PD was possible with reconstruction of the gastroduodenal artery, the procedure was abandoned due to patient- and tumor-related factors.
|
Figure 3. Celiac artery stenosis (black arrow) with tortuous pancreaticoduodenal arcade (white arrow). Atherosclerotic changes in the major arteries. |
|
|
Overall, in only 2 out of 53 (3.8%) patients with arterial anomalies was the PD abandoned (one case of a replaced right hepatic artery from the superior mesenteric artery encased by the tumor and another patient with celiac artery stenosis). The reason for abandoning PD in these patients was related to the size of the tumor (greater than 5 cm), the risk of positive resection margins, the advanced age of the patient with coronary artery disease and atherosclerosis, and was not related to the abnormal artery itself.
Comparison of Patients with and without Arterial Anomalies
The mean blood loss in the group with arterial anomalies was 450±54 mL (range: 270-630 mL) and in those without arterial anomaly was 415±61 mL (range: 290-540 mL) (P<0.001). The patients with arterial anomalies had a prolonged operating time. The mean duration of surgery was 420±32 minutes (range: 300-540 minutes) in patients with arterial anomaly versus 370±38 minutes (range: 240-500 minutes) in those without arterial anomalies (P=0.005). The mean duration of surgery was 412±35 minutes (range: 315-510 minutes) in the 38 patients who underwent PD with preoperatively known arterial anomalies versus 420±44 minutes (range: 300-540 minutes) in those (no. 15) where the arterial anomalies were detected during surgery (P=0.489).
The overall complication rate, mortality and length of hospital stay were not significantly different between the two groups (Table 3). Eleven (5.6%) out of 198 PD specimens had positive resection margins (9 retroperitoneal margins defined as the rim of the connective tissue being rich in lymphatics and nerve plexus separating the uncinate process from the superior mesenteric artery, and 2 common bile duct margins). No patient with arterial anomalies had positive resection margins.
|
Table 3. Comparison of patients with or without arterial anomalies (No. 200). |
|||
|
Variables |
Patients with arterial anomalies (No. 53) |
Patients without arterial anomalies (No. 147) |
P value |
|
Overall
complications |
16 (30.2%) |
43 (29.3%) |
1.000 b |
|
Duration of surgerya (minutes) |
414±37 (300-540) |
370±38 (240-500) |
<0.001 c |
|
Operative blood lossa (mL) |
450±54 (270-630) |
415±61 (290-540) |
<0.001 c |
|
Length of hospital staya (days) |
10.6±6.0 (4-27) |
9.9±5.1 (4-26) |
0.462 c |
|
a mean±SD (range) |
|||
DISCUSSION
Celiac and mesenteric axes are known for anatomical variations. Knowledge of the hepatic arterial blood supply is essential when planning a PD in order to avoid unnecessary surgical complications. Almost all anomalous arteries are known to have some variation in their course. These arteries may lie close to the tumor and can be damaged during the dissection or tumor cell spillage may occur. Variations in hepatic arterial anatomy are known to range from 21 to 45% [1, 2, 3, 4]. In our experience, the incidence of arterial anomalies was 26.5%. The limitation of our study is that the reported incidences of arterial anomalies may not be a true representation of anomalies in general as we did not routinely perform a preoperative CT angiogram or selective mesenteric angiography; however, the overall spectrum of our arterial anomalies matches well with a recent report [5].
Anomalous right hepatic artery is reported to be the most common arterial anomaly encountered during PD [5]. Our study suggests that 35 (66.0%) of all arterial anomalies were anomalous right hepatic arteries of which the majority were replaced right hepatic arteries arising from the superior mesenteric artery. These arteries lie close to the uncinate process and course posterolaterally to the hepatoduodenal ligament. It is necessary to identify them routinely before proceeding to resection of the pancreatic head and the uncinate process and also when the common bile duct is dissected and divided. The presence of these anomalies adds to the operative complexities, although this finding was not supported by a recent report by Jah et al. [6] which showed that the presence of aberrant right hepatic arteries was not associated with a significant increase in operative complexities but was a trend towards a prolonged operating time; more intraoperative blood loss was noted in patients with aberrant right arteries undergoing PD. We were able to perform PD in all of them except in one case where the artery was encased by the large tumor and the procedure was abandoned due to the tumor-related factors rather than due to the presence of the anomalous artery itself.
A replaced common hepatic artery from the superior mesenteric artery represents the variation commonly known as hepatomesenteric trunk [3, 7]. The replaced common hepatic artery may ascend along the ventral side of the pancreas (as in our series), between the pancreas and the portal vein, behind the portal vein or through the head of the pancreas. A PD preserving these arteries in patients with ampullary cancer is reported to be safe [8]. We managed to preserve the artery while performing a PD by separating and isolating it away from the tumor. This was possible due to the small size of the tumor and no gross involvement of the anomalous artery. There is a risk of tumor cell spillage while coring the anomalous artery out of the pancreatic capsule and the possibility of the transection line deviating to the right side while dividing the neck of the pancreas, leading to positive pancreatic resection margins [9, 10, 11]. Other possible options are either to sacrifice the artery or to reconstruct it in order to complete the procedure. Ligation of a replaced common hepatic artery can cause liver necrosis as these anomalous arteries are usually end arteries [12]. However, surgical experience with biliary tract malignancy shows that the right branch of the hepatic artery can be safely ligated without reconstruction provided the collateral arteries in the Glissonian sheath around the hepatic duct confluence are preserved [13]. Transient ischemic liver damage without serious postoperative complications has been reported when the PD was performed, ligating the replaced common hepatic artery without reconstruction [8] but experience is limited to a small number of patients. Reconstruction using an autologous vein or Gore-Tex interposition grafts is a reasonable option in these circumstances but it is reported to be associated with an inherent risk of potentially fatal postoperative bleeding if a pancreatic fistula develops [14, 15, 16, 17].
In the case of celiac artery stenosis, division of the gastroduodenal artery poses an ischemic threat to the liver and biliary reconstruction. Such anomalies are found in 1 to 3% of PDs [18]. Celiac artery stenosis in the majority of patients is associated with atherosclerotic narrowing and adequate collateral arteries may coexist in up to 80% of cases [19, 20]. Ligation of the gastroduodenal artery is tolerated in such a situation as the hepatopetal arterial flow is preserved due to the alternate collateral pathways and a PD can be performed successfully without reconstruction as reported by Trede [18]. However, if the collaterals are inadequate, arterial reconstruction is needed [21]. Test occlusion of the gastroduodenal artery with diminished pulsation in the hepatic artery, as recommended by Bull et al. [22] is a reasonable guide to ligate or to reconstruct the gastroduodenal artery during a PD. Other possible options to deal with celiac artery stenosis are preoperative endovascular stents [23, 24, 25], balloon dilatation [26], release of median arcuate ligaments [22] and intraoperative revascularization [21, 27, 28]. A gastroduodenal artery-preserving PD has been described [29], particularly in benign conditions such as chronic pancreatitis [21], but it has limited application in pancreatic and periampullary malignancies because this could compromise the resection margins.
The overall postoperative complication after PD did not attain a statistically significant difference except for the duration of surgery in patients with or without arterial anomaly in our study, which is well supported by a recent report by Jah et al. [6]. However, the author in this study showed no statistical difference in operating time, but a trend towards a prolonged operating time was noted in patients undergoing a PD with arterial anomaly. The incidence of postoperative complications, operating time and blood loss reported in the current study is similar to what has been reported in another recent report by Yang et al. [5].
Arterial anomalies encountered during a PD are common. There is a need to identify them routinely and prevent inadvertent damage. Their presence can increase the operative complexity as reflected by the longer duration of the surgery. Interestingly, the duration of the surgery did not differ significantly between those patients whose arterial anomalies could be detected preoperatively and those which were detected intraoperatively.
Received October 10th, 2009 - Accepted November 9th, 2009
Keywords Pancreaticoduodenectomy; Vascular Malformations
Correspondence
Adarsh
Chaudhary
Department of Surgical Gastroenterology
Room No. 2208A
Sir Ganga Ram Hospital, Old Rajinder Nagar
New Delhi 110060
India
Phone: +91-11.4225.2226
Fax: +91-11.2586.1002
E-mail: adarsh_chaudhary@yahoo.com
