JOP. J Pancreas (Online) 2011 Nov 10; 12(6):607-609.



Ectopic Pancreas Presenting as Periampullary Tumor with Obstructive Jaundice and Pruritus Is a Rare Diagnostic and Therapeutic Dilemma. A Case Report



Ram Nawal Rao, Yadav Kamlesh, Gupta Pallav, Nidhi Singla



Department of Pathology, Sanjay Gandhi Postgraduate Institute of Medical Sciences. Lucknow, UP, India




Context Ectopic pancreatic rest is an uncommon condition resulting in diverse clinical and pathological presentation. It results from altered development of two primitive pancreatic buds that fuse to form the uncinate-head and body-tail of normal gland. Ectopic pancreas is an anomaly where an ectopic rest develops at a place away from the normal site. Case report We describe a 48-year-old male patient who presented with progressive jaundice and pruritus. He was established to have a periampullary mass highly suggestive of malignancy, for which he undergo pancreaticoduodenectomy. However, histology showed ectopic pancreatic tissue in the periampullary region. Conclusion This case highlights importance of preoperative histological diagnosis of periampullary tumors to avoid morbid surgical procedure in the form pancreaticoduodenectomy. Ectopic pancreas should include differential diagnosis of periampullary tumors.





Ectopic pancreas is comparatively rare developmental abnormality, which can be noted both during operations and post-mortem autopsies. It usually occurs in the upper gastrointestinal tract, the commonest sites being duodenum (27.5%), stomach (25-35%) and jejunum (15.9%) [1]. We report a patient presenting with symptoms of ampullary tumor with obstructive jaundice and pruritus, but the radiological imaging study did not suggest the possibility of ectopic pancreas preoperatively. Clinically, ectopic pancreas is identified with an expected frequency of one in every 500 upper abdominal operations [2]. Less than 25 cases of ectopic pancreas at periampullary region have been reported so far in the literature [3, 4, 5, 6, 7, 8, 9].




A 48-year-old male presented with progressive jaundice and pruritus for 2 months. There was no history of anorexia, GI bleeding, loss of weight or vomiting. Patient had history of cigarette smoking since 15 years (1-2 daily) without past medical history of alcohol habits. No history of previous surgery was done. Patient had undergone magnetic cholangiopancreatography (MRCP) followed by endoscopic retrograde cholangiopancreatography (ERCP) with stenting at a centre outside before being referred to our hospital for further one management. On physical examination patient was conscious and oriented. Patient had jaundice and on abdominal examination there was organomegaly. Peripheral lymph nodes were not palpable. Pulse rate was 80/min, regular and blood pressure was 110/70 mmHg. Other vital systems were within normal limits.

On investigation routine hemogram was normal and serum biochemical analysis showed raised serum total bilirubin with predominance of conjugated fraction (6.5 mg/dL; reference range: 0-0.4 mg/dL). CA 19-9 was within normal range (2.36 U/mL; reference range: 1.2-30.9 U/mL). Ultrasound abdomen showed mild thickening and edema in gallbladder wall. Rest of the abdominal organs was normal. Contrast enhanced computed tomography (CECT) showed no focal lesion in liver; however, mild intrahepatic biliary radicle dilatation with pneumobilia was noted. Common bile duct stent in situ was seen and proximal common bile duct was dilated. Gallbladder wall was thickened and edematous. Subcentimeter lymph nodes were seen at porta and around celiac axis. MRCP showed diffuse gallbladder wall thickening with calculi. A small rounded soft tissue lesion was seen in periampullary region and protruding into duodenal lumen. ERCP was done outside and showed smooth papilla and normal mucosa for which needle knife papillotomy and stenting was done.

On laparoscopy there was no evidence of dissemination in the form of liver metastasis, peritoneal/serosal or pelvic deposits. Ascites was not seen. Pancreas was soft and main pancreatic duct was 2.0 mm. A 1.5x1.0 cm nodular lesion was identified in the periampullary area. A single soft common hepatic artery lymph node was also seen. Staging laparoscopy and pylorus preserving pancreaticoduodenectomy was done.


Gross Feature


Pancreaticoduodenectomy specimen showed a growth measuring 1.5x1.0 cm. in the periampullary region. Cut surface showed yellow variegated solid mass (Figure 1). It was entirely separate from the native pancreas.



Figure 1. Pancreaticoduodenectomy specimen showed a growth measuring 1.5x1.0 cm. in the periampullary region (arrow).



Histopathological Examination


Histopathological examination of the surgical specimen from periampullary nodule showed ectopic pancreatic tissue composed of ducts, acini, and well-formed islets in the mucosa and submucosa of the duodenum (Figure 2). Focal area of mucosal ulceration was seen (Figure 3). Even on extensive sampling of the specimen there was no gross or microscopic evidence of malignancy seen.



Figure 2. Histopathology section showed ectopic pancreatic tissue composed of ducts, acini, and well-formed islets in the mucosa and submucosa of the duodenum (arrow).



Figure 3. Section showed focal ulceration and mixed inflammation of mucosa in pariampullary region (arrow).





Ectopic pancreatic tissue turn out during surgical exploration is rare, accounting for less than 0.5% of laparotomy, but it is found in 13.7% of autopsies [3]. Common sites of ectopic pancreas are duodenum and gastric mucosa although theoretically it can occur anywhere in the body. Few cases have been reported in the literature as periampullary mass lesion resulting in obstructive jaundice [10, 11, 12]. Clinical presentation of our case is similar to the earlier cases which reported in literature as mimicker of periampullary carcinoma.

Hammastromm et al. described 10 cases of ectopic pancreatic tissue in which one patient had endoscopic sphincterotomy done and the endoscopic biopsy revealed ectopic pancreas [7]. Ectopic pancreas can mimick cholangiocarcinoma rarely [13]. Exact preoperative diagnosis of ectopic pancreas in the periampullary region using endoscopy and radiological imaging is difficult. The presence of central umbilication on endoscopy, though a characteristic finding in ectopic pancreas, is quite infrequent. Ectopic pancreas creating clinico-pathologic diagnostic dilemma resulting in Whipple procedure is reported in literature [4]. In 1859, Klob presented histological confirmation of ectopic pancreatic tissue in two cases [14].

CECT did not appear to be helpful in establishing the diagnosis of ectopic pancreas preoperatively. In our case, MRCP showed a small rounded soft tissue lesion in periampullary region and protruding into duodenal lumen. Magnetic resonance imaging or cholangiopancreatography (MRI/MRCP) was done only in one other case [9] where it was also not helpful in making the diagnosis. Endoscopic ultrasound (EUS) may have an important role to play in the diagnosis. At EUS, ectopic pancreas in the upper gastrointestinal tract is usually hypoechoic and heterogeneous with indistinct margins and is most commonly seen to arise from the submucosa. However, EUS was performed in only one of the 22 patients with periampullary heterotopic pancreas in the earlier series. Although EUS suggested benign pathology, it misdiagnosed the ectopic pancreas as a leiomyoma [4].

The local excision of ectopic pancreas when sufficient, rather than radical operation, can be the treatment of choice [5]. However, given the difficulties with correct preoperative diagnosis and the suspicion of an underlying periampullary malignancy, pancreaticoduodenectomy was performed in 14 (64%) of the 22 patients. Five patients were successfully managed by local excision (three by ampullectomy and two by excision of the common bile duct). Among three patients who had ampullectomy, the benign nature of the pathology was suggested by either EUS [4] or per-operative frozen section biopsy [6] or pre-operative endoscopic biopsy [8].




Ectopic pancreas in the periampullary region presenting as malignancy with progressive jaundice and pruritus is a rare entity and remains difficult to diagnose, despite advances in radiological and endoscopic imaging techniques. Our patient was clinically diagnosed as periampullary tumor due to ectopic pancreas highlights importance of preoperative histological diagnosis of mass in periampullary region to avoid morbid surgical procedure in the form of pancreaticoduodenectomy. Ectopic pancreas should include differential diagnosis of periampullary tumors, although rare in the lists.



Received July 26th, 2011 - Accepted September 6th, 2011


Keywords Jaundice, Obstructive; Neoplasms; Pancreas


Conflict of interest The authors have no potential conflicts of interest


Correspondence Ram Nawal Rao
Department of Pathology
1st Floor, New Diagnostic Block
Sanjay Gandhi Postgraduate Institute of Medical Science
Lucknow, UP, 226014
Phone: +91-0522.249.5259
Fax: + 91.0522.266.8017; +91-0522.266.8078



1.    Dolan RV, ReMine WH, Dockerty MB. The fate of heterotopic pancreatic tissue. A study of 212 cases. Arch Surg 1974; 109:762-5. (More details: [1]).

2.    Barbosa JC, Dockerty M, Waugh JM. Pancreatic heterotopia. Review of the literature andreport of41authenticated surgical cases of which 25 were clinically significant. Surg Gynecol Obstet 1946; 82:527-42. (More details: [2]).

3.    Pearson S. Aberrant pancreas: review of the literature and report of three cases, one of which a produced common and pancreatic duct obstruction. AMA Arch Surg 1951; 63:168-86. (More details: [3]).

4.    Chen CH, Yang CC, Yeh YH, Chou DA, Kuo CL. Ectopic pancreas located in the major duodenal papilla: case report and review. Gastrointest Endosc 2001; 53:121-3. (More details: [4]).

5.    Molinari M, Ong A, Farolan MJ, Helton WS, Espat NJ. Pancreatic heterotopia and other uncommon causes of non-malignant biliary obstruction. Surg Oncol 2000; 9:135-42. (More details: [5]).

6.    Laughlin EH, Keown ME, Jackson JE. Heterotopic pancreas obstructing the ampulla of Vater. Arch Surg 1983; 118:979-80. (More details: [6]).

7.    Hammarstrom LE, Nordgren H. Ectopic pancreas of the ampulla of Vater. Endoscopy 1999; 31:S67. (More details: [7]).

8.    Contini S, Zinicola R, Bonati L, Caruana P. Heterotopic pancreas in the ampulla of Vater. Minerva Chir 2003; 58:405-8. (More details: [8]).

9.    Obermaier R, Walch A, Kurtz C, von Dobschuetz E, Adam U, Neeff H, et al. Heterotopic pancreatitis with obstruction of the major duodenal papilla - A rare trigger of obstructive orthotopic pancreatitis. Pancreatology 2004; 4:244-8. (More details: [9]).

10. Hsu SD, Chan DC, Hsieh HF, Chen TW, Yu JC, Chou SJ. Ectopic pancreas presenting as ampulla of Vatertumor. Am J Surg 2008; 195:498-500. (More details: [10]).

11. Wagle PK, Shetty GS, Sampat M, Patel K. Ectopic pancreatic tissue mimicking ampullary tumor. Indian J Gastroenterol 2005; 24:265-6. (More details: [11]).

12. Filippou DK, Vezakis A, Filippou G, Condilis N, Rizos S, Skandalakis P. A rare case of ectopic pancreas in the ampulla of Vater presented with obstructive jaundice. Ann Ital Chir 2006; 77:517-9. (More details: [12]).

13. Biswas A, Husain EA, Feakins RM, Abraham AT. Heterotpic pancreas mimicking cholangiocarcinoma. Case report and literature review. JOP. J Pancreas (Online) 2007; 8:28-34. (More details: [13]).

14. Klob J. Pancreas accessorium. Zeitschrift der Kaiserl. Königl. Gesellschaft der Aerzte zu Wien 1859; 15:732. (More details: [14]).
